- Slide features: Soft close high quality side mount ball bearing slide, (W) groove with steel engagement pin designed for durable use, copper cylinder and dual closing springs.
- Length: 12″ (300mm)
- Extension length: 248mm
- Mounting type: Side Mount
- Closing type: Soft Close
- Load Capacity: 100 lb. (45 kg) / 18″
- Application: Frameless / Face Frame
- Height of slide: 45mm
- Required space: 1/2″ (12.7mm) each side
- Slide space adjustment: Ã‚Â±0.5mm
- Finishing: Nickel plated
- Main material: Cold-rolled steel
- Material thickness: 1.2-1.2-1.5mm
- IMPORTANT: For face-frame applications, (TCH-22201 R Z) Rear Mount Sockets are required.
